Heavy-duty ball caster with base flange
| Designation | Material of bearing ball | Dimensioning | Sealing felt | Load bearing capacity (kg) | |||||||
| Ø D1(mm) | Ø D2(mm) | H1(mm) | H3(mm) | H4(mm) | L1 x L1(mm) | L2 x L2(mm) | Ø D5(mm) | ||||
| Tolerances | – | – | +/- 0.1 | +/- 0.1 | +/- 0.1 | +/- 0.2 | – | – | – | – | – |
Solid ball caster / ball transfer units with base flange, gunmetal-finished |
|||||||||||
| 012.501 | Tool steel | 12.7 | 23.8 | 22.6 | 3.5 | 3.2 | dm 44.5 | dm 34.8 | 3.6 | no | 80 |
| 025.501 | 25.4 | 44.5 | 41.4 | 5.6 | 5.0 | 57.2 | 44.5 | 5.5 | yes | 150 | |
| 025.501b | 25.4 | 50.8 | 45.5 | 6.1 | 7.0 | 76.2 | 57.9 | 6.6 | yes | 350 | |
| 038.501 | 38.1 | 60.0 | 61.5 | 13.0 | 10.0 | 76.2 | 57.9 | 6.6 | yes | 1.000 | |
| 050.501 | 50.8 | 101.6 | 98.4 | 14.3 | 10.0 | 127.0 | 101.6 | 11.0 | yes | 2.000 | |
| 076.501 | 76.2 | 160 | 145 | 21 | 15 | 175.0 | 145.0 | 12.1 | yes | 4.500 | |
Design and construction
This Schulz ball caster / ball transfer unit consists of a casing, a top cover and a bearing cap as solid turned parts, a base flange, a bearing ball and several support balls.
Dimensions
The spacing is calculated by dividing the shortest edge length of the object to be transported by 3.5.
Materials
Casing: Steel gunmetal-finished, black
Deckel: Steel gunmetal-finished, black
Tragpilz: Stahl tempered
Support balls: Tool steel (tempered), Stainless steel (tempered)
Bearing ball: Tool steel (tempered), Stainless steel (tempered)
Operational conditions
Temperature range from -30°C to +100°C
Conveyance velocity of up to 2,0 m/s.
Dynamic load rating up to max. 2.000 kg.
Datenblatt Deutsch
Datasheet English
Fiche technique français
Hoja de datos español
Download “3D-PDF-Darstellung-025-050.501.pdf” 3D-PDF-Darstellung-025-050.501.pdf – Downloaded 2598 times – 122.95 KB Download “3D-Datensatz-025.501.igs” 3D-Datensatz-025.501.igs – Downloaded 2741 times – 163.68 KB Download “3D-Datensatz-038.501.jpg” 3D-Datensatz-038.501.jpg – Downloaded 2539 times – 95.82 KB Download “3D-038.500-Zusammenbau_IGES” 3D-038.500-Zusammenbau_IGES-1.igs – Downloaded 1421 times – 551.18 KB Download “3D-Datensatz-050.501.igs” 3D-Datensatz-050.501.igs – Downloaded 2731 times – 301.25 KB
In order to display and read the 3D PDF, you will need Acrobat Reader with an activated 3D function! Subject to technical changes and errors excepted!
